When the port is in data communications equipment (DCE) mode it indicates that Data Terminal Ready (DTR) and Request To Send (RTS) have been detected.
When the port is in data terminal equipment (DTE) mode the CONN LED indicates that Data Set Ready (DSR) Data Carrier Detect (DCD) and Clear To Send (CTS) have been detected. indicates that Data Set Ready (DSR) Data Carrier Detect (DCD) and Clear To Send (CTS). This connector is DB-60 on one end and can be V.35 RS-232 RS-449 X.21 or EIE-530 on the other end depending on your needs.* Uses the same cabling as Cisco 2500 and Cisco 7000 serial ports.* Does not support hot swap however no hardware damage will occur if it is swapped while the power is on.* Each serial card has one LED labeled CONN for each port which lights when the serial port is connected. Uses the same cabling as Cisco 2500 and Cisco 7000 serial ports. * One serial port.* Uses the Cisco 60-pin '5-in-1' connector.
The 1-port serial WAN interface card (WIC-1T) provides serial connections to remote sites or legacy serial network devices such as Synchronous Data Link Control (SDLC) concentrators alarm systems and packet over SONET (POS) devices. HPE Serial Console Server - Connecting Device Consoles or Modems to Serial Ports. Netra/Cisco RJ45 console port to Digi Netra/Cisco RJ45 console port to Cyclades.
